C-100 Brise Soleil

150917, C100, Office building, Budapest, Hungaria

The C100 louver is made of a high grade extruded aluminium, and is suited for external installations: horizontal, vertical, as well as sloping situations. The possibilities in width, height and shapes are almost ulimited.

Profile of the C100 louver

Profile C100 louver with width

Main technical dimensions for Brise Soleil

The figure below shows a schematic overview of a C100 system consisting of rafters and C100 louvers.





Aluminium louver C100



Size of louver

100 mm



Thickness of louver

1,2 mm



Louvers moveable

No



Interior

Yes



Exterior

Yes



Maximum Width

690 cm



Maximum Drop / Length

600 cm



Maximum area

40 m2



Louver - Louver distance (Step / Pitch)

Flex.



Different versions of the Brise Soleil

The are four different clips for the C100 louver.
In the following overview the clips withs corresponding angle are displayed.



A stylish and reliable Installation for every C100 System

The C100 System can be provided with 3 rafters. The size of the overhang influence which type of rafter is used. The clip determines the angele of the louver. Additionally, Sunshield has a broad experience and a large assorment of mounting brackets and methods. With that, a stylish and reliable installation is guaranteed for every blind in every situation. For each project, the Sunshield engineers provide a detailed installation scheme, customized to the specific situation of that project. It is guaranteed that the Sushield system gives an integrated view with the building.
