Aluminium Louver 155-E

Sunshield 155E louver

A 155-E louver system is a non-retractable slatted blind with 155-E louvers. These louvers are made from high-grade extruded aluminium, and have a width 155 mm. A 155-E louver system is suited for all kinds of internal and external installations; horizontal, vertical, sloping, and upside down. 155-E louvers are usually movable, but can also be placed in a fixed position.

Profile of the 155-E louver

The front, the visible side, of the 155-E louver has an almost flat shape. Besides a great overlap, this louver also interlocks. This makes the 155-E louver perfect for black-out systems. So when you are looking for a louver that allows you to darken a room by daylight, the 155-E should be on your short list. The back of the blade is designed for optimal fixation of the clip that holds the slat.

Drawing of the profile of the 155-E louver with width indication

THE 155-E Box LOUVER

There is something special about the backside of the 155-E louver. During extrusion, the back of the 155-E is equipped with an clipping mechanism, allowing the louver to be closed with a cover resulting in the 155-E Box.

Drawing of the profile of the 155-E box louver indication how it's closed

Drawing of the profile of the 155-E box louver with cover on louver

The 155-E louver system

The following image shows a schematic representation of a 155-E louver system. Such a system consists of at least two rack arms, and a number of louvers, blades.

Drawing representing rack arm distance of the L-system

Louver properties

Property
General
Louver type
155-E
Size of louver
155 mm
Thickness of louver
1,8 mm
Movable
0° – 90°
Louver distance / Step (S)*
140 mm
Maximum width (W)*
600 cm
Maximum drop / length (L)*
600 cm

Interior
Exterior
Maximum rack arm distance (X)
200 cm
180 cm
Maximum side overhang (Y)
50 cm
40 cm
Support distance


L 65 mm rack arm
250 cm
225 cm
L 120 mm rack arm
500 cm
400 cm
* = the number of rack arms placed on top, or next to each other, is unlimited.

Sunshield 155-E louvers, the blades, are moveable, and can be placed in any position from 0 to 90 degrees. Sunshield louver systems, the blinds, can be installed horizontal, vertical, in any desired slope, and upside down.
