L-system fixing clip

Louvers need to be connected to slat clips. This is taken into account when designing extruded aluminum louvers. In order to connect wooden louvers with slat clips, a fixing clip is mounted to the wooden profile. The S-system and L-system have different slat clips, so the wooden louvers regarding require different fixing clips.

This page shows the fixing clip for wooden louvers using the L-system.

L-system fixing clip wood louver

L-system fixing clip wood louverThe L-system fixing clip wood louver is a profile with a width of 80 mm. The fixing clip is connected to the wood with two 3,5x9,5 screws.

Slat clip connected to fixing clip

L-system slat clip connected to fixing clip wood louver

The L-system slat clip is connected (clipped) to the fixing clips.
