S-system fixing clip
Louvers need to be connected to slat clips. This is taken into account when designing extruded aluminum louvers. In order to connect wooden louvers with slat clips, a fixing clip is mounted to the wooden profile. The S-system and L-system have different slat clips, so the wooden louvers regarding require different fixing clips.
This page shows the fixing clip for wooden louvers using the S-system.
S-system fixing clip wood louver
The S-system fixing clip woord louver is connected to the wood with two 3,5x9,5 screws.
Slat clip connected to fixing clip
The S-system slat clip is connected (clipped) to the fixing clips. After that, the slat clip is secured with a 3,5x13 locking screw.
